PD5F SMD High Voltage Diode 5KV 100mA 70nS

Products Main features:
1、SMD connection.
2、High thermal conductivity epoxy compound molding.
3、Fast recovery time for high efficiency.
4、Gullwing(Outer Bend) shapes.
5、Ultra small size package
6、Fast recovery PF Series are the same package size.
GET A QUOTE Download
  • PD5F SMD High Voltage Diode 5KV 100mA 70nS
  • PD5F SMD High Voltage Diode 5KV 100mA 70nS
  • PD5F SMD High Voltage Diode 5KV 100mA 70nS
  • PD5F SMD High Voltage Diode 5KV 100mA 70nS
  • PD5F SMD High Voltage Diode 5KV 100mA 70nS
Desciption
 PD5F SMD High Voltage Diode Data Sheet
 Parameter Symbol Unit Test Conditions Value
 Repetitive Peak Backward Voltage Vrrm KV Ta=25℃  Ir=1.0μA 5
 Peak Working Backward Voltage Vrwm KV Ta=25℃  Ir=1.0μA 5
 Average Forward Current If(AV) mA 50Hz Half-sine Wave , Resistance load @Tbreak=50℃ 100
 Backward Recovery Time Trr nS   70
 Surge Forward Current Ifsm A 0.01S @ Half-Sine wave  50Hz 10
 Operating Ambient Temperature Ta   -55~+175
 Storage Temperature Tstg   -55~+150
 Forward Peak Voltage Vfm V   ≥3.7
 Backward Peak  Current Irrm1 μA @ Ta=25℃ VRM=VRRM 1.0
Irrm2 μA @ Ta=100℃ VRM=VRRM 20.0
 Absolute Maximum Ratings & Electrical Characteristics
